EM / IC Reader Wiegand 26,

Weatherproof (ABA Optional)


Supporting Card:EM4100 card serial number ,ISO/IEC14443A/B, ISO15693 & ISO18092

Read Distance :> 8cm(Depending on label sizeand surroundings)

Interface :Wiegand26/34,RS232,RS485,ABA (TVS transient pulse protection)

Power Supply:DC9V ~ 12V

Current : <50mA

Operating Temperature :-10ºC ~ 70ºC

Humidity :0 ~ 95%

48mm*12.5mm*80mm


Mini Card Reader: RFID type ID access control card reader, Reading Distance is about 3-15CM; Support Wiegand 26bits/ Wiegand34bits /ABA Standard Format Data Output. It's widely use for Access control, Parking lot, Campus ID, Time attendance, Hotel Management,

Features:
- Support UEM 4100 ID Card or compatible with it( 64bits, Manchester Code) or Mifare 1 Card (13.56 MHz Frequency)
- Built-in Antenna
- Built-in LED (Double Color LED)
- Built-in Loud Speaker (Buzzer)
