SB-100/SB-100T/SB-100ST

Feedback

We will carefully read your message and reply you as soon as possible.

Products Support Business Solution Career

  • Overview
  • Specifications
  • More
  • Quote

1. SB-100 is a multi function low temperature electronic door lock with door status  signal output,

2. low temperature design, which makes access safer and durable.

3. High-strength aluminum alloy lock body, stainlesss teel lock head

4.which is fail safe electric bot  lock that suitable for glass door, wooden door, metal door .


◆Face Plate: 205Lx35WX41.5H(mm)

◆Strike: 90Lx25Wx2H(mm)

◆Bolt: 16mm

◆Voltage: 12VDC    Low Temprature

◆Start Current: 900mA

◆Standby Current: 100mA

◆Solid Bolt: Polishing housing, 800Kg Holding Force

◆Suitable For: Woodeng Door,Glass Door,Metal Door

◆Induction Distance: 8mm

◆Face Place Material: High Aluminum,Carrulous Line Finished

◆Optional Bracket: SBK3,SBK5

◆Weight: 0.6 kg


◆SB-100N :Fail Safe Electric Bolt, Normal Temprature

◆SB-100:  Fail Safe Electric Bolt

◆SB-100S :Fail Safe Electric Bolt W/Signal NC/CO

◆SB-100T: Fail Safe time delay,0,3,6,9 sec

◆SB-100ST:Fail Safe Electric Bolt W/Signal output & Time Delay  0,3,6,9 se
