l Waterproof, conforms to IP68
l Strong Zinc Alloy Electroplated anti-vandal case
l Full programming from the keypad
l 2000 uses, supports Card, PIN, Card + PIN
l Can be used as a stand alone keypad
l Backlight keys
l Wiegand 26 output for connection to a controller
l Adjustable Door Output time, Alarm time, Door Open time
l Very low power consumption (30mA)
l Fast operating speed, <20ms with 2000 users
l Lock output current short circuit protection
l Easy to install and program
l Built in light dependent resistor (LDR) for anti tamper
l Built in buzzer
l Red, Yellow and Green LEDS display the working status
Operating Voltage | DC 12V-24 ±10% |
User Capacity | 2000 |
Card Reading Distance | 3-6 cm |
Active Current | ＜60mA |
Idle Current | 25±5 mA |
Lock Output Load | Max 20A |
Alarm Output Load | Max 20A |
Operating Temperature | -45～60℃ |
Operating Humidity | 10%- 90% RH |
Environment | Conforms to IP68 |
Adjustable Door Relay time | 0 -99 seconds |
Adjustable Alarm Time | 0- 3 minutes |
Wiegand Interface | Wiegand 26 bit |
Wiring Connections | Electric Lock, Exit Button, External Alarm |
Dimensions | L120 x W78 x H20 mm |
